Product Description
Radiator Size
240 mm
Radiator Dimensions (WxDxH)
277 x 119.6 x 27.2mm / 10.90 x 4.69 x 1.06 inches
Radiator Material
Aluminum
Water Cooling Tube Material
EPDM
Water Cooling Tube Length
390 mm / 15.35 inches
Number of Fans
2
Fan Dimensions (WxDxH)
120 x 120 x 25 mm / 4.7 x 4.7 x 0.98 inches
Fan Air Flow
62.6 CFM
Fan Noise Level
31.1 dBA
Fan Bearing
Rifle Bearing
Fan Life Expectancy
40,000 hrs@40℃
Fan Rated Current
0.15A(Max:0.18A)
Fan Power Consumption
1.8W(Max:2.16W)
PWM Mode
Yes
Cable Length (PWM Cable)
450 mm; 17.71 inches
Fan Connector
5V ARGB 3-PIN Header
Block Lighting
ARGB Gen2
Fan Lighting
ARGB Gen2
Pump Life Expectancy
25,000 hours in typical use
Pump Noise Level
20 dBA (avg.)
Pump Rated Current
0.24A
Pump Power Consumption
2.88W
Pump Speed
3800 RPM ± 10%
Pump Connector
3-PIN Header
5V ARGB 3-PIN Header ( Female )
5V ARGB 3-PIN Header ( Female )
Cold Plate Material
Copper
Block Dimensions (WxDxH)
70.9 x 69.3 x 56.98 mm
Intel Socket Support
LGA 1700 / 1851
AMD Socket Support
AM5 / AM4
Accessories
Thermal paste x 1
Screws x 8
Screws x 8
