Product Description
Overview
Dimensions
442 x 325 x 44 mm (17.4 x 12.8 x 1.7")
UniFi Application Suite
Protect
Yes
Access
Yes
Managed Cameras
(60) HD (30) 2K (18) 4K
Storage Capacity
(4) 3.5" drive bays
Data Protection
Yes
Vantage Point
Yes
Networking Interface
(1) 10G SFP+ (1) GbE
Power Redundancy
Yes
Form Factor
Rack mount (1U)
Door Access Support
Yes
Hardware
Hard Drive Capacity
(4) 2.5/3.5” HDD / SSD support
Max. Power Budget for Drives
75W
Max. Power Consumption
100W
Power Method
(1) Universal AC input, 100—240V AC, 2A Max., 50/60 Hz (1) USP-RPS DC input, 11.5V DC, 10.43A
Power Supply
AC/DC, internal, 120W
Processor
Quad ARM® Cortex®-A57 cores at 1.7GHz
Memory
4GB
Management
Ethernet
Weight
Without mounting brackets: 5.1 kg (11.3 lb) With mounting brackets: 5.2 kg (11.5 lb)
Enclosure Material
SGCC steel
Mount Material
SGCC steel
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
