Product Description
Dimensions
442.4 x 400 x 44 mm (17.4 x 15.7 x 1.7")
Port Layout
1 GbE RJ45
32 (24 PoE+; 8 PoE++) (1G/100M/10M)
2.5 GbE RJ45
16 (8 PoE+; 8 PoE++) (2.5G/1G/100M/10M)
10G SFP+
4 (10G/1G)
Max. PoE Output
Up to PoE++
Total PoE Availability
720W
Redundancy
DC Power Backup
Layer 3✓
Form Factor
Rack mount (1U)
Etherlighting™âœ“
Switching Capacity
224 Gbps
Total Non-Blocking Throughput
112 Gbps
Forwarding Rate
167 Mpps
Supported VLANs
1,000
MAC Address Table Size
32,000
L3 Table Size
ARP Entries
12,000
IPv4 Routes
12,000
Packet Buffer Size
2 MB
Access Lists
IPv4
128
MAC
128
DHCP Server (Local Networks)✓
DHCP Relay✓
Inter-VLAN Routing (Local Networks)✓
Static Routing (Local Networks)✓
LACP Port Aggregation✓
STP & RSTP✓
QoS (DSCP)✓
Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)✓
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)✓
IGMP Snooping✓
802.1X Control✓
MAC-Based ACLs & Device Isolation✓
DHCP Snooping & Guarding✓
Egress Rate Limit✓
Flow Control✓
Storm Control✓
Multicast & Broadcast Rate Limiting✓
MAC Address Blocking✓
IP-Based ACLs & Network Isolation✓
MAC-Based Port Restriction✓
Port Isolation✓
Port Mirroring✓
Jumbo Frames✓
LLDP-MED✓
Voice VLAN✓
Loop Protection✓
PoE Ports
PoE+
32
PoE++
16
Max. PoE Wattage per Port by PSE
PoE
15.4W
PoE+
32W
PoE++
64W
Max. Power Consumption
100W (Excluding PoE Output) 820W (Including PoE Output)
Power Method
(1) Universal input, 100—240V AC, 50/60 Hz (1) USP RPS DC input
Power Input Method
AC input
Power Supply
AC/DC, internal, 870W
Supported Voltage Range
100—240V AC
Management
Ethernet AR
Heat Dissipation (Excluding PoE Output)
341.2 BTU/hr
Weight
Without mounting brackets: 6.2 kg (13.7 lb) With mounting brackets: 6.3 kg (13.9 lb)
Enclosure Material
SGCC steel
Mount Material
SGCC steel
Supported Rack Depth
400~1200 mm (15.7-47.2")
LCM Display
1.3" touchscreen
ESD Protection
Air: ± 16kV, contact: ± 12kV
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
Etherlighting™
Ethernet✓
SFP+✓
NDAA Compliant✓
Certifications
CE, FCC, IC, Anatel
