Product Description
Video & Channels
-
Channels: 8 IP camera inputs
-
Max Resolution per Channel: Up to 8 MP (4K)
-
Decoding Capability:
-
1 × 8 MP @ 30fps
-
4 × 4 MP @ 30fps
-
8 × 1080P @ 30fps
-
Compression & Storage
-
Video Formats: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
-
HDD Support: 1 × SATA interface (up to 16 TB)
-
Recording Modes: Manual, schedule, motion detection, alarm
Connectivity
-
Network Interface: 1 × RJ-45 (10/100/1000 Mbps)
-
Video Outputs: 1 × HDMI (up to 4K), 1 × VGA
-
USB: 2 × USB 2.0
-
Audio I/O: 1 in, 1 out (RCA)
-
No PoE ports — requires an external PoE switch or injectors
Performance
-
Incoming Bandwidth: 128 Mbps
-
Outgoing Bandwidth: 64 Mbps
-
Protocols: TCP/IP, IPv4/IPv6, HTTP, HTTPS, RTSP, UDP, NTP, DHCP, DNS, P2P
-
Remote Access: DMSS app (iOS/Android), browser access
Power & Physical
-
Power Supply: DC 12 V / 2 A
-
Consumption: ≤6.3 W (without HDD)
-
Dimensions: 260 × 232 × 47.6 mm
-
Weight: 1.0 kg (net)
-
Operating Temp: –10 °C to +55 °C
Key Features
-
4K HDMI output
-
Smart codec technology for reduced storage and bandwidth
-
ONVIF compatible
-
Remote and mobile viewing
-
Fanless design for quiet operation
