Product Description
Product specs
GS15949515901080
PNPWUP-OL300BA-AZ01B
PhaseSingle Phase
Technology On-line (VFI)
TypologyRack (2U) / Convertible
Output waveformPure Sine Wave
Output Power Factor1.0
Power3KVA / 3KW
Input Nominal Voltage230V
Input Voltage Range
110-300 VAC ± 5% @ 50% load
160-300 VAC ± 5% @ 100% load
Input Nominal Frequency50 Hz / 60 Hz (Auto Sensing)
Output Nominal Voltage200*/208*/220/230/240 VAC
Output Voltage Precision± 1%
Outlets
8 x IEC C13 + 1 x IEC C19 (4 x Programmable power management outlets)
LCD DisplayYes
Batteries PresenceInternal and / or External
Batteries Installed
6x HR09122F
*for replacement please check accesories tab
Efficiencyup to 96%*
Communication PortsRS232USBSNMPEPO
Typical Backup Time11 minutes @ 50% load (1500W)
Parallel operationNot Supported
Generator CompatibleYes
Noise Level<50dB
Features
Auto-Restart while AC is recovering
Cold start
Internal bypass
Hot swappable battery design
External battery pack (optional)
User-friendly and easy-shift LCD
Dimensions (L x W x H)630 x 438 x 88 mm
Weight27.5 kg
