Product Description
Technology
Projection System
3LCD Technology, RGB liquid crystal shutterLCD Panel
0,59 inch with C2 FineImage
Color Light Output
3.700 Lumen- 2.400 Lumen (economy) In accordance with IDMS15.4White Light Output
3.700 Lumen - 2.400 Lumen (economy) In accordance with ISO 21118:2020Resolution
WXGAResolution Enhancement
HD readyAspect Ratio
16:10Contrast Ratio
16.000 : 1Light source
LampLamp
UHE, 210 W, 6.000 h durability, 12.000 h durability (economy mode)Keystone Correction
Auto vertical: ± 30 °, Manual horizontal ± 30 °2D Vertical Refresh Rate
100 Hz - 120 HzColour Reproduction
Upto 1.07 billion coloursOptical
Throw Ratio
1,30 - 1,56:1Zoom
Manual, Factor: 1 - 1,2Lens
OpticalScreen Size
33 inches - 320 inchesProjection Distance Wide/Tele
1,68 m - 2,02 m ( 60 inch screenProjection Lens F Number
1,49 - 1,72Projection Lens Focal Length
16,9 mm - 20,28 mmProjection Lens Focus
ManualOffset
10 : 1Connectivity
Interfaces
USB 2.0-A, USB 2.0, VGA in, HDMI in, Composite in, Wireless LAN IEEE 802.11b/g/n (optional), Cinch audio inEpson iProjection App
Ad-Hoc / InfrastructureAdvanced Features
Security
Kensington lock, Security cable hole, Wireless LAN unit lock, Password protection3D
No2D Colour Modes
Dynamic, Cinema, Presentation, sRGB, BlackboardOther features
AV Mute Slide, Auto source search, Built-in speaker, Horizontal and vertical keystone correction, Long lamp life, Quick Corner, Split-Screen-FunctionVideo Color Modes
Blackboard, Cinema, Dynamic, Presentation, sRGBGeneral
Power consumption
286 Watt (Normal On-Mode), 327 Watt (Normal Peak-mode), 225 Watt (Eco Peak-Mode), 0,3 Watt (Energy saving standby)Supply Voltage
AC 100 V - 240 V, 50 Hz - 60 HzProduct dimensions
302 x 237 x 82 mm (Width x Depth x Height)Product weight
2,5 kgNoise Level
Normal: 37 dB (A) - Economy: 28 dB (A)Supported Temperature
Operation 5° C - 35° C, Storage -10° C - 60° CSupported Humidity
Operation 20% - 80%, Storage 10% - 90%If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.
If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.
